Heavy duty blue 1100*800*140mm flat nine-foot printing plastic tray
product features:
(1) Injection molding integrated molding, single-sided flat design, easy to manually extract on four sides, improve work efficiency.
(2) The bottom reinforcement ribs, the indentation of the forks is densely designed, and the impact resistance is stronger.
(3) High-density polyethylene HDPE raw material or impact-resistant polypropylene PP raw material is adopted. The product is non-toxic, non-absorbent, moisture-proof and mildew-proof, resistant to corrosion and insects, no nails, no sprinkles, and can be recycled.
(4) The section of the bearing surface of the product is “T” type rib structure, which increases the bearing capacity of the bearing surface. The “T” type panel will not produce crush marks on the package, which is beneficial to protect the outer packaging of the product.
(5) Fine workmanship, smooth surface without burrs, strong and strong.
(6) It is not easy to collapse and deform, and it is more firm, and it has strong product stability, bearing capacity, cold resistance and heat resistance.
| Product size | 1100mm×800mm×140 mm |
| Product load | Static load:2.0 T | Dynamic load:1.0 T |
| Product weight | 13.6kg±0.1kg |
| The main raw material | high density polyethylene (HDPE) |
| Operating temperature | -30℃～60℃ |
| Product color | according to customer needs (default is blue) |
| Marking method | mold stereotype |
| | screen printing |
| Structural features | Panel type: | Flat |
| | Bottom type: | nine feet |
| | Pallet structure: | Facial: | Flat design |
| | | Bottom: | Encrypted lacing |
| | Production process: | injection molding |
1. Physical display:
product advantages:
(1) The whole plane design of the tray, no sanitary corners that are difficult to clean, and improve the hygiene of the tray;
(2)Nine-foot design, four-sided fork, suitable for a variety of forklifts
